PRINTED PARTS
| Name | Qty |
|---|---|
| MINI-x-carriage | 1 |
| MINI-x-end | 1 |
| MINI-z-carriage-front | 1 |
| MINI-z-carriage-rear | 1 |
| MINI-fan-spacer | 1 |
| MINI-fan-spacer-clip | 1 |
| MINI-minda-holder | 1 |
FASTENERS
| Name | Qty |
|---|---|
| M3x12 screw | 12 |
| M3x20 screw | 9 |
| M3x30 screw | 4 |
| M3x10 button head screw | 1 |
| M3x4 grub screw | 4 |
| M3n | 4 |
| M3nN | 1 |
| M3nS | 13 |
ELECTRICAL PARTS
| Name | Qty |
|---|---|
| MINI hotend thermistor | 1 |
| MINI heater | 1 |
| MINI heatsink fan (DS) | 1 |
| MINI print fan (DS) | 1 |
| MINI M.I.N.D.A. | 1 |
| 2S connector | 1 |
| MINI X-axis motor | 1 |
STANDARD PARTS
| Name | Qty |
|---|---|
| LM8UU linear bearing | 2 |
| LM10LUU linear bearing | 2 |
| Pulley Bearing Idler 623h | 1 |
| Pulley Motor GT2-16 | 1 |
| X-axis belt 561 mm | 1 |
CUSTOM PARTS
