PRINTED PARTS
| Name | Qty |
|---|---|
| MINI-y-belt-holder | 1 |
| MINI-y-idler | 1 |
| MINI-y-plate-front | 1 |
| MINI-y-plate-rear | 1 |
| MINI-heatbed-cable-cover-bottom | 1 |
| MINI-heatbed-cable-cover-top | 1 |
| MINI-display-box | 1 |
| MINI-knob | 1 |
FASTENERS
| Name | Qty |
|---|---|
| M3x8 screw | 15 |
| M3x12 screw | 7 |
| M3x20 screw | 3 |
| M5x20r screw | 8 |
| M3x4 Torx | 9 |
| M3nN | 11 |
| M3nS | 2 |
| M3nE | 3 |
| M3x6 hex spacer | 9 |
ELECTRICAL PARTS
| Name | Qty |
|---|---|
| MINI heatbed | 1 |
| MINI heatbed termistor | 1 |
| MINI heatbed cable | 1 |
| MINI Y-axis motor | 1 |
| MINI display (driver DS) (lcd module DS) | 1 |
| MINI lcd cable | 1 |
STANDARD PARTS
| Name | Qty |
|---|---|
| LM8UU linear bearing | 3 |
| Pulley Bearing Idler 623h | 1 |
| Pulley Motor GT2-16 | 1 |
| Y-axis belt 496 mm | 1 |
CUSTOM PARTS
| Name | Qty |
|---|---|
| MINI aluminium extrusion 262mm | 2 |
| MINI Y smooth rod | 2 |
| MINI Y carriage | 1 |
| MINI heatbed textile sleeve | 1 |
| U bolt | 3 |
| MINI steel sheet | 1 |
| MINI foam pad | 5 |
